Pullmaster M18 Series - Page 146

PAGE 29
APPENDIX A
240 REV.001122
POUNDS
(KILONEWTONS)
DRUM
CODE
CABLE DRUM SIZES
INCHES
(MILLIMETERS)
WIRE ROPE STORAGE
FEET
(METERS)
FEET/MINUTE
(METERS/MINUTE)
LINE PULL
AT MAXIMUM
PRESSURE*
BARREL FLANGE LENGTH 7/8 in 3/4 in 5/8 in
-1 8.5 15.5 10.0 113 170 239 18000 11288 122 195 1.3
(216) (394) (254) (34) (52) (73) (80.1) (50.2) (37) (59) (4.9)
-2 13.0 20.0 16.0 251 375 528 12109 8649 182 255 3.7
(330) (508) (406) (77) (114) (161) (53.9) (38.5) (55) (78) (14)
-3 8.5 20.0 16.0 372 500 747 18000 8649 122 255 2.1
(216) (508) (406) (113) (152) (228) (80.1) (38.5) (37) (78) (7.9)
-4 8.5 28.0 21.3 1068 1479 2130 18000 6110 122 360 2.9
(216) (711) (541) (326) (451) (649) (80.1) (27.2) (37) (110) (11.0)
DRUM DRUM DRUM DRUM
LINE SPEED
AT MAXIMUM
VOLUME*
* Performance specifications are based on standard hydraulic motor with 3/4 inch diameter rope.
BARE FULL BARE FULL
LUBRICATING
OIL
VOLUME
REQUIRED
U.S.
GALLONS
(LITERS)
