Pullmaster M18 Series - Parts Reference

PAGE 28
100 * 1 FINAL HOUSING
103 26631 1 BEARING - SPHER. ROLLER SKF # 23948 CC OR EQ.
104 26634 1 CIRCLIP ROTOR CLIP DHO-320
105 25511 1 OIL SEAL 10.000 X 11.250 X .625
106 23841 1 RETAINING RING INT 5/32 X 1/4 X 11.5 OD
120 23846 1 END COVER
121 25237 6 PIPE PLUG 3/4 NPT SOC STEEL, AIRWAY #5409-12
122 23817 2 SUNGEAR STOPPER
123 26638 1 O-RING -392 23"ID 3/16" CS
126 23805 1 PLANET HUB STOPPER - FINAL
127 25158 4 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.75 GR 5
130 20677 1 BREATHER RELIEF ASSEMBLY
299 23544 1 SUB-ASSEMBLY SECONDARY PLANETARY DRIVE
340 * 1 SUNGEAR H/M75 FINAL
341 * 1 SUNGEAR EXTENSION
342 * 1 TAPERED PIN
343 * 1 SET SCREW 1-8 UNC X 2" LG.
344 25514 1 CIRCLIP ROTOR CLIP SH-500
349 23750 1 SUB-ASSY FINAL PLANETARY DRIVE
399 24093 1 SUB-ASSY PRIMARY PLANETARY DRIVE
430 23541 1 INTERNAL GEAR H/M30 PRIMARY
431 25338 1 CIRCLIP ROTOR CLIP SH-300
432 20417 1 RETAINING RING INTERNAL
434 20452 1 SPACER
440 23782 1 SUNGEAR PRIMARY
451 23811 1 PLANET HUB STOPPER - SECONDARY
456 23763 1 SECONDARY HOUSING
457 25085 1 PIPE PLUG 3/8 NPT SOC STEEL,AIRWAY#5409-6
490 23776 1 SUNGEAR - SECONDARY
491 26640 1 CIRCLIP ROTOR CLIP SH-237
500 * 1 CABLE DRUM
501 23084 1 RETAINER
502 25264 1 CAPSCREW - SOCKET HEAD 3/8 - 16UNC X 1.0 GR 5
503 25037 1 LOCKWASHERS 3/8
513 26633 1 CIRCLIP ROTOR CLIP SH-950
531 25670 1 OIL SEAL 8.500 X 10.000 X .562
532 20898 1 RETAINING RING INT 5/32 X 1/4 X 10.88 OD
533 26632 1 BEARING - SPHER. ROLLER SKF # 23936 CC OR EQ.
537 25081 50 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.50 GR 5
539 25840 1 O-RING -282 16" ID 1/8" CS
541 25014 52 LOCKWASHER 1/2"
550 * 2 BASE PLATE
551 25572 * CAPSCREW - HEX HEAD 3/4 - 10NC X 2.50 GR 5
553 25299 * LOCKWASHER 3/4"
556 * 2 TIE BAR
600 20445 1 CONNECTING SHAFT
601 25341 1 O-RING -239 3-5/8"ID.1/8"CS
603 25334 1 NEEDLE BEARING TORRINGTON # B-3012
REF NO.
DESCRIPTION
QTY.
PART NO.
PARTS REFERENCE
354 REV.060315
