PAGE 11
TROUBLE SHOOTING
240 REV.951201
FAILURE
PROBABLE CAUSE
Winch will not produce line pull at maximum
pressure as listed in SPECIFICATIONS.
Winch does not produce line speed at maximum
volume as listed in SPECIFICATIONS.
Winch will not reverse.
a) Winch is mounted to an uneven surface.
(See INSTALLATION INSTRUCTIONS.)
b) Cable sheaves or block purchase operated with the
winch are not turning freely.
c) Damage or wear in the hydraulic motor.
d) Excessive back pressure in the hydraulic system.
e) Relief valve may be set too low. (See SPECIFICATIONS
for maximum operating pressure.)
a) Winch is mounted to an uneven surface.
(See INSTALLATION INSTRUCTIONS.)
b) Cable sheaves or block purchase operated with the
winch are not turning freely.
c) Damage or wear in the hydraulic motor
d) Excessive back pressure in the hydraulic circuit.
a) Leakage out of the brake piston prevents the disc brake
from being released against the brake springs. This is
caused by damaged O-ring seals on the brake piston.
b) The O-ring seals, on the brake release channel between
the motor adaptor and the brake housing, is damaged.
If this failure occurs there will be substantial leakage
from between the motor adaptor and brake housing.
c) Insufficient hydraulic pressure. (See SPECIFICATIONS
for minimum operating pressure.)
d) Winch is mounted to an uneven surface.
(See INSTALLATION INSTRUCTIONS.)
e) Hydraulic pressure is not reaching the brake piston due
to plugged brake release orifice in the brake housing.
GENERAL:
In most cases, when the hydraulic winch does not perform satisfactorily, the cause of malfunction is found
somewhere in the hydraulic circuit. Before the winch is removed from its mounting and disassembled, all of the
hydraulic circuit components should be checked for proper function.
IMPORTANT:
The hydraulic oil volume relates to the line speed or rpm of the winch.
Therefore, if the winch does not produce the specified maximum rated line speed or drum rpm, a loss of hydraulic
flow somewhere in the hydraulic circuit can be analysed. If this condition exists, install a flow meter into the
hydraulic circuit to check the volume of oil supplied to the pressure port of the hydraulic winch motor when the
winch control is completely opened. The flow meter should indicate the maximum operating volume. If this test
indicates a loss of hydraulic flow, check the hydraulic pump, the relief valve and the control valve. If the pump
is driven by V-belts, check for belt slippage.
The hydraulic pressure relates to the line pull or lifting capacity of the winch.
If the winch will not produce the specified maximum line pull, install a pressure gauge in the pressure line leading
to the hoisting port on the hydraulic winch motor. Stall the winch to prevent rotation of the drum and then open
the control valve. Check the hydraulic pressure reading of the installed pressure gauge. If the pressure reads
below the specified maximum operating pressure, look for trouble in the hydraulic pump, the relief valve and the
control valve. If the hydraulic pump is driven by V-belts, check for belt slippage. When checking oil pressure and
volume in the hydraulic circuit, verify that the hydraulic reservoir is filled to the top level and the hydraulic pump
is running at maximum operating rpm.
Only if the hydraulic system has been checked and found to be in order, use the following indications for probable
causes of failure in the winch:
