PAGE 33
354 REV.051117
INSTALLATION DRAWING
U
L
L
M
PRESSURIZE FOR
CLOCKWISE
ROTATION
ROTATION
COUNTER-CLOCKWISE
PRESSURIZE FOR
*
CLOCKWISE
1/4 - 18NPT
GAGES PORTS
4 JACKING
SCREWS 3/4NC
(41)
1.62
P
K c/c
R c/c
THE CABLE DRUM HAS TWO WIRE ROPE FERRULE POCKETS TO
SUIT FERRULES SIZES FROM 2-1/8 - 2-13/16 OUTSIDE DIA. AND
FROM 2-3/4 - 3-3/16 LONG.
MAXIMUM WIRE SIZE IS 1-1/2
PORT 3/4 ORB
CIRCULATION INLET
OIL LEVEL PLUG 3/4-14 NPT
(LUBRICATING OIL)
DRAIN PORT
1/2-14 NPT
(CIRCULATING OIL)
*
TO ESTABLISH THE DRUM ROTATION FOR HOISTING OR PULLING
REFER TO BRAKE CODE (EXPLANATION OF MODEL CODING).
CLOCKWISE OR COUNTER-CLOCKWISE DRUM ROTATION IS
ESTABLISHED BY LOOKING AT THE HYDRAULIC MOTOR.
A MINIMUM 5 WRAPS OF WIRE
ROPE UNDER TENSION MUST
BE MAINTAINED AT ALL TIMES!
FOR SAFETY:
2.0" (CODE 61)
SAE 4 BOLT FLANGE
MOTOR PORTS
CIRCULATION
RETURN PORT
1 1/4 ORB
DRAIN PORT
3/8-18 NPT
(LUBRICATING OIL)
(LUBRICATING OIL)
3/4-14 NPT
FILLER PORT
DRAIN PORT
3/4-14 NPT
(LUBRICATING OIL)
8 MOUNTING HOLES -1 5/16 DIA.
USE 1 1/4" MOUNTING BOLTS
GRADE 8 OR BETTER
DRAIN PORT 3/4-14 NPT
(LUBRICATING OIL)
FILLER/DRAIN PORT
3/4-14 NPT
(LUBRICATING OIL)
S
T
N H
C
(517)
20.4
G
F
J
(248)
9.8
D c/c
E
I 1105
(549)
21.6
(520)
20.8
U
33.8
(859)(187)
7.4
7.2
(183) (782)
30.8
TS
(952.5)
37.500
(1099)
43.3
(376)
14.8
(1010)
39.8
(314)
12.4
(76.2)
3.00
(2157)
84.9
(1016)
40.0
(1349)
53.1
(1019)
40.1
(527)
20.8
(1231.9)
48.500
(914)
36
(965)
38
(356)
14
(800.1)
31.500
(955)
37.8
(332)
13.1
(857)
33.8
(238)
9.4
(82.6)
3.25
(1706)
67.2
(610)
24.0
(905)
35.6
(625)
24.6
(451)
17.8
(825.5)
32.500
(508)
20
(813)
32
(406)
16
-4
-1
RPNMLKJHGFEDCBA
CODE
DRUM
Dimensions in inches
(Dimensions in millimeters)
