PAGE 21
316 REV.980601
PARTS REFERENCE
ITEM NO. QTY. PART NO. DESCRIPTION
100 1 20072 FINAL HOUSING
103 2 25007 BALL BEARING 070 X 110 X 20 #6014
104 1 25006 CIRCLIP ROTOR CLIP HO-433
105 1 25008 OIL SEAL 3.000 X 4.003 X .375
120 1 20071 END COVER
121 1 25032 PIPE PLUG 1/2 NPT SOC HD
122 1 20063 SUNGEAR STOPPER
123 1 25069 O-RING -274 10" ID 1/8" CS
124 1 20898 RETAINING RING
126 1 20092 PLANET HUB STOPPER
130 1 20458 BREATHER RELIEF
300 1 20073 PLANET HUB
310 3 20079 PLANET PIN
311 3 25091 CIRCLIP ROTOR CLIP SH-87
313 3 25004 CIRCLIP ROTOR CLIP C-87
320 3 20076 PLANET GEAR
321 6 25068 THRUST WASHER TORRINGTON #TRA 1423
323 3 25005 NEEDLE BEARING TORRINGTON #B1416
340 1 * FINAL SUNGEAR
343 2 25239 CIRCLIP ANDERTON #A1000 - 0150
344 1 20082 SUNGEAR STOPPER
400 1 20069 PLANET HUB
410 3 20080 PLANET PIN
411 6 25119 CIRCLIP ROTOR CLIP SH-62
420 3 20075 PLANET GEAR
421 6 25064 THRUST WASHER TORRINGTON #TRA 1018
423 3 25063 NEEDLE BEARING TORRINGTON #B1012
440 1 22882 PRIMARY SUNGEAR
500 1 * CABLE DRUM
502 1 20085 CABLE ANCHOR
503 1 25085 PIPE PLUG 3/8 NPT SOC HD
513 1 25055 CIRCLIP ROTOR CLIP SH-262
517 1 26280 CIRCLIP ROTOR CLIP HO-187
530 1 * BEARING FLANGE
531 1 25062 OIL SEAL
535 1 25012 CIRCLIP ROTOR CLIP SH-275
537 6 25001 CAPSCREW - SOC HD 5/16 - 18NC X .62 GRADE 5
538 1 20377 SEAL CARRIER
539 2 25061 O-RING -163 6" ID 3/32" CS
543 1 25281 SEAL - PARKER 3" ID #1870 - 3000
545 1 25280 O-RING -90 DURO -154 3-3/4" ID 3/32" CS
550 1 * BASE
693 2 25271 CAPSCREW - FLAT HD 5/16 - 18NC X .75
695 1 25026 O-RING -248 4-3/4" ID 1/8" CS
698 1 20379 END HOUSING
700 1 20334 BRAKE HOUSING
703 1 25388 PLASTIC CAPLUG 1/2 NPT
706 1 20086 JOURNAL BEARING
712 1 20024 BRAKE SPACER
713 5 25024 DIVIDER PLATE
715 4 20034 FRICTION PLATE
719 1 25539 CIRCLIP ROTOR CLIP SE-118
720 1 22881 BRAKE HUB
*These parts vary according to drum code.
Refer to APPENDIX B.
