PAGE 4
CLOCKWISE ROTATION:
The drum rotation of the standard PULLMASTER Model M6 planetary winch is counterclockwise for hoisting, when
looking at the hydraulic motor of the winch. Drum rotation for clockwise hoisting direction is available as an option.
EXTERNAL BRAKE RELEASE:
PULLMASTER planetary winches can be supplied with an external brake release which permits release of the
automatic disc brake from an external pressure source.
FAILURE TO PROPERLY VENT EXTERNAL BRAKE RELEASE
PORT WILL TRAP BRAKE PRESSURE AND ALLOW THE
LOAD TO DROP, CAUSING PROPERTY DAMAGE, SEVERE
INJURY OR DEATH. WINCHES SUPPLIED WITH EXTERNAL
RELEASE OPTION MUST BE CONNECTED ACCORDING
TO TYPICAL HYDRAULIC CIRCUIT.
DANGER
CABLE DRUM SIZES:
Aside from the standard drum sizes listed in APPENDIX A, the PULLMASTER Model M6 planetary winch can be
supplied with optional drums to accommodate large wire rope storage capacity.
DRUM GROOVING:
Cable drums for the PULLMASTER Model M6 planetary winch can be grooved. Where this option is a requirement,
it is necessary to state the size of wire rope which is to be used with the winch.
OPTIONAL HYDRAULIC MOTORS:
The performance of the standard PULLMASTER Model M6 planetary winch may be changed by using a different
displacement motor. (Contact the factory for performance information.)
The PULLMASTER WINCH CORPORATION will consider other options for quantity requirements.
184 REV.970901
OPTIONS
