PAGE 22
Refer to PAGE 28 for ASSEMBLY DRAWING.
PARTS REFERENCE - BRAKE GROUP
249 REV.110817
400 1 20404 PLANET HUB
401 1 20417 RETAINING RING
410 3 20369 PLANET PIN
411 3 25004 CIRCLIP ROTOR CLIP C-87
413 3 25091 CIRCLIP ROTOR CLIP SH-87
420 3 20370 PLANET GEAR
421 6 25068 THRUST WASHER TORRINGTON # TRA 1423
423 60 25270 LOOSE ROLLER 5/32 X 1.25 TOR. #E151 - Q
430 1 20411 INTERNAL GEAR
431 1 25338 CIRCLIP ROTOR CLIP SH-300
434 1 20452 SPACER
440 1 20414 SUNGEAR
444 1 20419 SUNGEAR STOPPER
530 1 * BEARING FLANGE
531 1 26359 OIL SEAL
533 1 25333 BALL BEARING #6026
534 1 20461 BEARING RETAINER
537 6 25081 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.50 GRADE 5
539 1 25109 O-RING -269 8-3/4" ID 1/8" CS
541 6 25014 LOCKWASHER 1/2"
600 1 20445 CONNECTING SHAFT
601 1 25341 O-RING -239 3-5/8" ID 1/8" CS
603 1 25334 NEEDLE BEARING TORRINGTON #B2812
606 1 21086 BACKUP WASHER
607 1 25345 OIL SEAL
700 1 20447 BRAKE HOUSING
703 1 25347 PLASTIC CAPLUG 1 NPT THR' D
707 1 25339 O-RING -278 12" ID 1/8" CS
712 1 20451 BRAKE SPACER
713 6 25305 DIVIDER PLATE
715 5 25304 FRICTION PLATE
719 1 25336 CIRCLIP ROTOR CLIP SH-187
720 1 20446 BRAKE HUB
722 1 20455 SPRAG CLUTCH ALIGNER
723 1 25303 SPRAG CLUTCH BORG WARNER #140373 B
724 1 20421 SPRAG CLUTCH ALIGNER
727 1 25335 CIRCLIP ROTOR CLIP SH-196
734 1 20422 PLUG
735 1 25344 O-RING -123 1-3/16" ID 3/32" CS
750 1 20397 PISTON
751 1 25343 O-RING -90 DURO -451 11" ID 1/4" CS
752 14 20413 BRAKE SPRING
753 1 25342 O-RING -90 DURO -452 11-1/2" ID 1/4" CS
23126 WINCH SEAL KIT, CONSISTS OF ITEMS:
105, 123, 257, 265, 531, 539, 601, 606,
607, 707, 735, 751, 753 AND 801
* This part varies according to drum code.
Refer to APPENDIX B.
ITEM NO.
DESCRIPTION
PART NO.
QTY.
