PAGE 11
FAILURE
PROBABLE CAUSE
Winch will not produce line pull at maximum
pressure as listed in SPECIFICATIONS.
GENERAL:
In most cases, when the hydraulic winch does not perform satisfactorily, the cause of malfunction is found
somewhere in the hydraulic circuit. Before the winch is removed from its mounting and disassembled, all of the
hydraulic circuit components should be checked for proper function.
IMPORTANT:
The hydraulic oil volume relates to the line speed or rpm of the winch.
Therefore, if the winch does not produce the maximum rated line speed, a loss of hydraulic flow somewhere in
the hydraulic circuit system can be analysed. If this condition exists, install a flow meter into the hydraulic circuit
to check the volume supplied to the motor ports when the winch control is completely opened. The flow meter
should indicate the maximum operating volume. If the test described indicates a loss of hydraulic flow, check
the hydraulic pump, the relief valve and the control valve.
The hydraulic pressure relates to the line pull or lifting capacity of the winch.
If the winch will not pull the maximum rated load, install a pressure gauge into the pressure line leading to the
pulling port on the hydraulic winch motor. Stall the winch to prevent rotation of the drum and then open the control
valve and check the hydraulic pressure reading of the installed pressure gauge. If the pressure reads below the
specified maximum operating pressure, look for trouble in the hydraulic pump, the relief valve and the control
valve. When checking oil pressure of oil volume anywhere in the hydraulic system, make certain that the hydraulic
pump is running at maximum operating rpm. Installations using a belt drive for hydraulic pump must be checked
for belt slippage. Verify that hydraulic reservoir is filled to the top level.
Only if the hydraulic system has been checked and found to be in order, use the following indications for probable
causes of failure in the winch:
a) Winch is mounted to an uneven surface (see
INSTALLATION INSTRUCTIONS).
b) Cable sheaves or block purchase operated with the
winch are not turning freely.
c) Damage or wear in the hydraulic motor.
d) Excessive back pressure in the hydraulic system.
e) Relief valve may be set too low.
a) Winch is mounted to an uneven surface (see
INSTALLATION INSTRUCTIONS).
b) Cable sheaves or block purchase operated with the
winch are not turning freely.
c) Damage or wear in the hydraulic motor
d) Excessive back pressure in the hydraulic circuit.
a) Leakage out of the brake piston prevents the brake
from being released against the brake springs. This is
caused by damaged O-ring seals on the brake piston.
b) The O-ring seals, on the brake release channel between
the motor adaptor and the brake housing is damaged.
If this failure occurs there will be substantial leakage
from between the motor adaptor and brake housing.
c) Insufficient hydraulic pressure (see SPECIFICATIONS
for minimum operating pressure).
d) Winch is mounted to an uneven surface (see
INSTALLATION INSTRUCTIONS).
e) Hydraulic pressure is not reaching the brake piston
(plugged brake release orifice in the brake housing).
Winch will not produce line speed at maximum
volume as listed in SPECIFICATIONS.
Winch will not reverse.
184 REV.950201
TROUBLE SHOOTING
