PAGE 22
PARTS REFERENCE - BRAKE GROUP
ITEM NO.
QTY.
PART NO.
DESCRIPTION
293 1 25584 O-RING - 016 5/8 "ID 1/16" CS
340 1 21121 FINAL SUNGEAR
507 1 25664 SPHERICAL ROLLER BEARING SKF # 22211CC
515 1 25665 OIL SEAL 3.375 X 4.000 X .500
615 2 26229 THRUST WASHER TORRINGTON # FTRA 4060
617 1 25667 THRUST BEARING TORRINGTON # FNT 4060
700 1 * BRAKE HOUSING
706 1 21048 BRONZE WASHER
707 1 25061 O-RING - 163 6" ID 3/32" CS
708 1 * CHECK VALVE
709 1 * PLASTIC CAPLUG 1/8 NPT
710 1 20896 BACK-UP WASHER
711 1 25666 OIL SEAL**
712 1 20874 BRAKE SPACER
713 14 25624 DIVIDER PLATE
715 13 25623 FRICTION PLATE
720 1 20890 BRAKE HUB
722 1 20421 SPRAG CLUTCH ALIGNER
723 1 25303 SPRAG CLUTCH BORG WARNER # 140373 "B"
724 1 20421 SPRAG CLUTCH ALIGNER
727 1 25335 CIRCLIP ROTOR CLIP SH-196
730 1 20891 BRAKE SHAFT
750 1 * PISTON
751 1 25629 O-RING - 90 DURO - 253 5-3/8" ID 1/8" CS
752 8 20859 BRAKE SPRING
753 1 25630 O-RING - 90 DURO - 256 5-3/4" ID 1/8" CS
755 1 * *
759 1 * STEEL BALL 5/32 DIAMETER
762 1 * BALL STOPPER
800 1 * MOTOR ADAPTOR
811 1 26624 O-RING 100 MM ID x 2 MM CS
815 2 25013 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.25 GR 5
817 2 25014 LOCKWASHER 1/2"
821 6 25013 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.25 GR 5
823 6 25014 LOCKWASHER 1/2"
830 1 20902 CONNECTING TUBE
831 2 25018 O-RING - 010 1/4" ID 1/16" CS
832 2 21524 CHECK VALVE
834 2 25738 O-RING .306 ID X .034 C/S
840 1 20870 SAFETY VALVE
850 1 * MOTOR - 070 HIGH TORQUE LOW SPEED 12.9 CID
955 2 25687 PLASTIC CAPLUG SAE # 10 ORB
970 2 20892 TIE BAR
971 16 25265 CAPSCREW - HEX HEAD 7/16 - 14NC X 1.25 GR 5
973 16 25328 LOCKWASHER 7/16"
23118 MOTOR SEAL KIT
* These part numbers and descriptions vary according to brake code.
Refer to APPENDIX B.
** Do not substitute.
Available from PULLMASTER or Authorized Dealer only.
Refer to PAGE 20 for winch seal kit and PAGE 24 for ASSEMBLY DRAWING.
184 REV.060714
