Pullmaster M8 Series - Page 144

PAGE 27
240 REV.030505
INSTALLATION DIMENSIONS
MOTOR GEAR MOTOR PORT SIZE I L
CODE WIDTH SAE 4 BOLT FLANGE
- 042 2.50 8.1 2.5
(63.5) (205) (64)
- 101 2.25 7.8 2.5
(57.2) (198) (64)
-102 2.00 7.6 2.5
(50.8) (192) (64)
1.50 inch
- 128 1.75 Code 61 7.3 2.5
(44.5) (186) (64)
- 161 1.00 6.6 2.5
(25.4) (167) (64)
- 163 1.25 6.9 2.5
(31.2) (173) (64)
- 162 1.50 7.1 2.5
(38.1) (180) (64)
Dimensions in inches
(Dimensions in millimeters)
COMMERCIAL M365 GEAR MOTORS
-1 8.5 15.5 10.0 8.3 17.9 17.9 15.4 9.430 25.9 3.0 10.13 12.9 18.4 13.500 17.8 5.8
(216) (394) (254) (210) (454) (454) (392) (239.52) (659) (76) (257.2) (329) (468) (342.90) (451) (147)
- 2 13.0 20.0 16.0 8.4 20.8 18.5 22.0 18.500 32.2 1.8 10.75 13.5 23.3 17.250 21.6 6.3
(330) (508) (406) (214) (527) (470) (559) (469.90) (817) (44) (273.1) (342) (591) (438.15) (546) (159)
- 3 8.5 20.0 16.0 8.4 20.8 18.5 22.0 18.500 32.2 1.8 10.75 13.5 23.3 17.250 21.6 6.3
(216) (508) (406) (214) (527) (470) (559) (469.90) (817) (44) (273.1) (342) (591) (438.15) (546) (159)
- 4 8.5 28.0 21.3 8.8 28.8 22.5 28.1 24.187 38.3 1.9 14.75 16.0 31.3 20.500 25.0 8.8
(216) (711) (540) (225) (730) (572) (714) (614.35) (977) (49) (375) (405) (795) (520.70) (635) (223)
DRUM
CODE
E
FGDCA
HJKM
NP R
B
S
T
Dimensions in inches
(Dimensions in millimeters)
COMMERCIAL “WM” TWO-SPEED GEAR MOTORS
HYDRAULIC MOTORS
MOTOR GEAR MOTOR PORT SIZE I L PORT PORT
CODE WIDTH SAE 4 BOLT FLANGE 'X' 'Y'
- 143 2.50 + 2.50 14.7 2.9 DRAIN LOW
63.5 + 63.5 (373) (74) SPEED
1.25 inch
- 148 2.50 + 2.50 Code 61 14.7 2.9 HIGH DRAIN
63.5 + 63.5 (373) (74) SPEED
