Pulnix TM-7 - 8 Timing Charts

SECTION 8 TIMING CHART
Image sensing period
Optical
black period
Dummy
H register
H register
stop period
Optical
black period
CCD photo sensors
allocation
CCD output
signal
Effective picture
period
HD
6.7µSec
96
6
45 70 22 5
818
768
45
154
H BLK 10.7µSec
22
1.54µSec
68
H SYNC
4.75µSec
64
4.47µSec
756
52.81µSec
Composite video
output
69.8nSec
763 764 765 766 767 768
B1 B2 B3 B4 B5
1 2 3 4 5 6 7 8 9 10
757 758 759 760 761 762 763 764 765 766 767 768 B1 B45
B1 B45
D1 D22
910
63.56µSec (1 horizontal line)
10
