Pulsafeeder MicroVision EX - Calibrating PTSA Probe

72-901-04 Rev A 8/12/2019
Page 14 of 24
4-20mA
The content of the following registers is model dependent and will have no valid
meaning unless the associated hardware is present and configured correctly.
The following registers are available on all models.
Modbus Name
Start
Address
End
Address
Data
Type
Details
4-20mA Input 1
milliamp
measurement
30001
30002
float
The raw current
measurement
Translated 4-
20mA Input 1
milliamp
measurement
30103
30104
float
The raw current
measurement
transformed to represent
the selected sensor
The following registers are available on all models except CXXE and C5XE – See
appendix A.
Modbus Name
Start
Address
End
Address
Data
Type
Details
4-20mA Input 2
milliamp
measurement
30005
30006
float
The raw current
measurement
Translated 4-
20mA Input 2
milliamp
measurement
30007
30008
float
The raw current
measurement
transformed to represent
the selected sensor
