Pulsafeeder MicroVision EX User Manual

72-901-04 Rev A 8/12/2019
Page 6 of 24
Relay 1 Timer Set
Point Mode
30017
30017
UINT16
0= Setpoint Mode Disabled
1 = MVEX Conductivity Probe
2 = MVEX pH Probe
3 = MVEX ORP Probe
4= mS / CM via 4-20mA Input 1
5 = pH via 4-20mA Input 1
6 = mV via 4-20mA Input 1
7 = PPB via 4-20mA Input 1
8 = PPM via 4-20mA Input 1
9 = % via 4-20mA Input 1
10 = mS / CM via 4-20mA Input 2
11 = pH via 4-20mA Input 2
12 = mV via 4-20mA Input 2
13 = PPB via 4-20mA Input 2
14 = PPM via 4-20mA Input 2
15= % via 4-20mA Input 2
Relay 1
Measurement
Value
30018
30019
FLOAT
Relay 1 Relay
State Bit Field
30020
30021
UINT16
0 = Relay is OFF
1 = Relay is ON
Relay 2 Status
Depending on the model this relay may be pH, ORP, or a Timer. Refer to Relay 1
table for field details.
Modbus Name
Start
Address
End
Address
Data
Type
Details
Relay 2 Run Time
30021
30022
UINT32
Relay 2 HOA Run
Time Remain
30023
30024
UINT32
Relay 2 HOA
Mode
30025
30025
UINT16
Relay 2 HOA Run
Time Set
30026
30027
UINT32
Relay 2 Relay
Cnfg.
30028
30028
UINT16
Relay 2 Timer Set
Point Mode
30029
30029
UINT16
Relay 2
Measurement
Value
30030
30032
FLOAT
Relay 2 Relay
State Bit Field
30032
30032
UINT16
