5. Appendix A: MVEX Model Features
Model /
CXXE
C5XE
CPXX
COXX
CPOX
Control
Parameters
Conductivity
only
Conductivity
only
Conductivity
& PH
Conductivity
& ORP
Conductivity
& PH & ORP
Relay 1
Conductivity
Probe
Conductivity
Probe
Conductivity
Probe
Conductivity
Probe
Conductivity
Probe
Relay 2
Timer 1
Timer 1
pH Probe
ORP Probe
pH Probe
Relay 3
Timer 2
Timer 2
Timer 1
Timer 1
ORP Probe
Relay 4
Timer 3
Timer 3
Timer 2
Timer 2
Timer 1
Relay 5
N/A
Timer 4
Timer 3
Timer 3
Timer 2
Relay 6
N/A
Timer 4
Timer 4
Timer 3
Relay 7
Timer 5
Timer 5
Timer 4
Relay 8
Timer 6
Timer 6
Timer 5
4-20mA Input 1
Yes, if installed
Yes, if installed
Yes, if installed
Yes, if installed
Yes, if installed
4-20mA Input 2
N/A
N/A
Yes, if installed
Yes, if installed
Yes, if installed
4-20mA output 1
Yes, if installed
Yes, if installed
Yes, if installed
Yes, if installed
Yes, if installed
4-20mA output 2
N/A
N/A
Yes, if installed
Yes, if installed
Yes, if installed
4-20mA output 3
Yes, if installed
Yes, if installed
Yes, if installed
4-20mA output 4
Yes, if installed
Yes, if installed
Yes, if installed
Flow Switch
INSTALLED
INSTALLED
INSTALLED
INSTALLED
INSTALLED
Drum Level 1
INSTALLED
INSTALLED
INSTALLED
INSTALLED
INSTALLED
Drum Level 2
INSTALLED
INSTALLED
INSTALLED
INSTALLED
INSTALLED
Drum Level 3
INSTALLED
INSTALLED
INSTALLED
INSTALLED
INSTALLED
Water Mater 1
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Water Meter 2
Dry Contact
Dry Contact
Dry Contact
Dry Contact
Dry Contact
Water Meter 3
N/A
N/A
Dry Contact
Dry Contact
Dry Contact
Water Meter 4
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Water Meter 5
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Water Meter 6
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
Dry Contact or
Hall Effect
