Pulsar Axion 2 User Manual

Status Bar
The status bar at the bottom of the display shows current operating statuses
via icons, including:
Colour Mode (shown only when the Black Hot colour mode is selected)
Amplification level
Smoothing Filter (displayed when the function is on)
Calibration Mode (in Automatic calibration mode a countdown timer
will appear instead of the calibration mode icon 3 seconds
before automatic calibration begins).
Microphone
Magnification
Wi-Fi Connection
Time
Power Indication:
- charge level if the device is powered by a battery
- charge level if the device is charging and powered by a battery
- no battery, the device is connected to an external power supply

Pulsar Axion 2 Specifications

General

Display Type	AMOLED
Video/Photo Recording	Yes
Built-in Memory	16 GB
Stream Vision 2 Compatibility	Yes
Ingress Protection	IPX7
Digital Zoom	4x
Display Resolution	1024x768
Wi-Fi	Yes
Sensor Resolution	640x480
Pixel Pitch	12μm
