Pulsar Axion 2 User Manual

Angular Field of
View (Horizontal x
Vertical), degree
10.7х8
Linear Field of
View, m at 100 m
18.2
Eyepiece Focus
Range, Dioptre
+4 / -5
Detection
Distance for Deer-
Sized Objects, m/y
1300 / 1422
Display

Type AMOLED
Resolution, Pixels 640x400
Operational
Characteristics

Power Supply, V 3 - 4.2
Battery
Type/Capacity/Nominal
Output Voltage
APS 5 Li-ion Battery Pack / 4900 mAh / DC
3.7 V
External Power
Supply
5 V, 9 V (USB Type-C)
Battery Run Time
at t=22°C, hours*
11
Degree of
Protection, IP
Code (IEC60529)
IPX7
Operating
Temperature
Range, °C / °F
-25 … +40 / -13 – +104
Dimensions,
mm/inch
152x50x74 / 5.98x1.97x2.91
