Pulsar AXION LRF XQ38 User Manual

ENGLISH
Specications
MODEL AXION LRF XQ38
SKU 77428
Microbolometer
Type uncooled
Resolution, Pixels 384x288
Pixel Pitch, µm 17
Frame rate, Hz 50
Optical characteristics
Optical magnication, x 3.5
Smooth digital zoom 3.5-14
Digital Zoom, x 2/4
Lens focus, mm 38
Focal ratio, D/f' 1.2
Minimum Focusing Distance, m 3
Eye relief diameter, mm 3.5
Angular eld of view (HxV), degree 9.8x7.4
Linear eld of view, m per 100 m 17.2
Eyepiece focusing range, Diopter +4/-5
Detection distance for deer-sized objects, (m) 1350
Display
Type AMOLED
Resolution, Pixels 1024x768
Operational characteristics
Power Supply, V 3-4.2 V
Battery Type APS 5 Li-ion Battery Pack
Capacity 4900 mAh
Nominal output voltage DC 3.7 V
External power supply 5-15 V (USB Type-C)
Battery run time at t=22 °C, h 5
Degree of protection, IP code (IEC60529) IPX7
Operating temperature range, °C -25 … +40
Dimensions, mm 167x74x73
Weight (without battery), kg 0.38
Characteristics of the rangender
Wavelength, nm 905
Measurement range, m* 1000
Measurement accuracy, m 1
* Depends on the characteristics of the object under observation and
environmental conditions.
Improvements may be made to the design of this product to enhance its user
features.
The current version of the User’s Manual can be found on the website www.
pulsar-vision.com
5

Pulsar AXION LRF XQ38 Specifications

General

Brand	Pulsar
Model	AXION LRF XQ38
Category	Monocular
Language	English
