Table 5. Mechanical parameters.
EN54M-2A7
EN54M- 2A7-17
EN54M- 3A7-17
EN54M- 3A17-40
EN54M- 5A7-17
EN54M- 5A17-40
EN54M- 5A40-65
EN54M- 10A17-40
EN54M- 10A40-65
Enclosure dimensions
(LxWxH)
200 x 120 x 48 [mm] [+/- 2mm]
204 x 141 x 52
[+/- 2mm]
237 x 168 x 55
[+/- 2mm]
Mounting (L1xW1)
(see Fig. 3)
212 x 75 x Φ5 [+/- 2mm]
216 x 88 x Φ5
[+/- 2mm]
249 x 84 x Φ5
[+/- 2mm]
Net/gross weight
0,95 kg
0,98 kg
1,48 kg
Terminals
Battery outputs BAT:
6,3F-2,5
Battery outputs BAT: Ф6 (M6-0-2,5)
Mains supply: Ф0,41÷2,59 (AWG 26-10), 0,5÷4mm
2
Outputs: Ф0,51÷2,05 (AWG 24-12), 0,5÷2,5mm
2
Notes
Convection cooling
Forced cooling
Table 6. Safety of use.
Protection class EN 60950-1:2007
I (first)
Protection grade EN 60529: 2003
IP00
Insulation electrical strength:
- between input (network) circuit and the output circuits of the PSU
- between input circuit and protection circuit
- between output circuit and protection circuit
3000 V AC min.
1500 V AC min.
500 V AC min.
Insulation resistance:
- between input circuit and output or protection circuit
100 MΩ, 500 V DC
Table 7. Recommended types and sections of installation cables.
Mains supply ~230 V L-N-PE (Table1 [1])
HDGs 3 x 0,75 mm
2
…1,5 mm
2
OMY 3 x 0,75 mm
2
…1,5 mm
2
AUX1, AUX2 output terminals (Table 1 [2])
HLGs 2 x 1,5 mm
2
…2,5 mm
2
Indication inputs/outputs (Table 1 [2])
YnTKSY 1 x 2 x 0,8 mm
2
