DESCRIPTION OF PRODUCT PARTS
As shown in Fig 1
1. Soft grip foam grip
2. Upper handle
3. Start Lever
4. Fixing knob with square neck bolt
5. Lower handle
6. Grass bag
7. Fuel tank cap
8. Primer
9. Height adjusting handle
10. Rear wheel
11. Engine oil cap
12. Side discharge cover
13. Side discharge chute
14. Deck
15. Spark plug boot
16. Pull start
17. Rear discharge cover
18. Front wheel
Fig 1
1
3
2
4
5
6
7
17
16
8
11
15
10
9
13
12
14
18
3
