Pure Humidifier EC-10 Installation Instructions

2
Capacity & Weights
Electrical Specifications
Electrical Specification
“EC” Series
Standard
Water Unit
Model No.
Steam Output Capacity †
Humidifier Weight
Empty Full
lbs/hr kg/hr lbs kg lbs kg
EC-5 15.0 6.8 139.0 63.1 223.0 101.2
EC-10 30.0 13.6 140.0 63.5 224.0 101.6
EC-15 45.0 20.4 141.0 64.0 225.0 102.1
EC-20 60.0 27.2 142.0 64.4 226.0 102.5
EC-25 75.0 34.0 143.0 64.9 227.0 103.0
EC-35 102.0 46.3 146.0 66.2 230.0 104.3
Capacity & Weights
“EC” Series
Standard
Water Unit
Model No.
Single Phase Amperage
Control
Circuit
Voltage
KW
No. of
Heaters 120V 208V 240V 480V 600V
No. of
Heaters 208V 240V 480V 600V
EC-5 5 Single 41.7* 24.0 20.8 10.4 8.3 Triple 13.9 12.0 6.0 4.8 24 vac
EC-10 10 Double 41.7 20.8 16.7 Triple 27.8 24.1 12.0 9.6 24 vac
EC-15 15 Triple 31.3 25.0 Triple 41.7 36.1 18.1 14.4 24 vac
EC-20 20 Triple 41.7 33.3 Triple 24.1 19.2 24 vac
EC-25 25 Triple 41.7 Triple 30.1 24.1 24 vac
Three Phase Amperage
EC-35 34 Triple Triple 40.9 32.7 24 vac
* EC-5 at 120/1 requires 3 heating elements.
† The above capacities are based on 100% efficiency. Actual humidifier capacity may vary due to the heat loss
from the humidifier reservoir. The ambient air temperature, air velocity, and injection tube system will affect
the rate of heat loss from the humidifier reservoir.
