Pure Humidifier EC-10 Installation Instructions

11
Optional Blower Pack
In applications where a ducted air system is not
available, PURE offers the optional Blower Pack.
The Blower Pack contains a two-speed
adjustable blower that moves the air over the
steam discharge outlet and disperses the steam
directly into the space (see Fig. 1). The Blower
Pack mounts directly on top of the “EC”
humidifier or can be remote mounted (see Fig.
2).
Locating Blower Pack
The distance that visible steam will travel after
leaving the Blower Pack is dependent upon the
relative humidity in the room and the capacity of
the humidifier. If this visible steam comes in
contact with any solid object (walls, beams,
machinery, etc.), it may form condensate and
drip. Refer to Fig. 3 and Table 4 (Table 4 is
located on page 12) for data on visible steam
travel. This will aid you in planning the location
of the Blower Pack.
Remote Mounting
The Blower Pack may be remote-mounted up to
ten feet away from the “EC” wall mount
humidifier (see Fig. 2).
Blower Pack
Air is drawn
into Blower Pack
Steam is discharged
directly into space
“EC” Wall Mount Humidifier
“EC” With Optional Blower Pack
Fig. 1
Visible Rise and Throw
Fig. 3
Remote-Mounted Blower Pack
Fig. 2
Throw
Rise
Blower Pack
Remote Blower Pack
“EC” Humidifier
6” Water Seal
