SMC4-4-16A16B. Four-axis motion controller

Edition of 03.08.2016

www.purelogic.ru8 (800) 555 63 74

M207 corresponding OUT_7 output low level (perfusion 500ma to ground)

M208 corresponding OUT_8 output low level (perfusion 500ma to ground)

M209 corresponding OUT_9 output low level (perfusion 500ma to ground)

Enter the judgment M command (M3 **, M4 **) M301 corresponding the input terminal INTPU_1 Judgment if it is low level execute the next line,

otherwise go on waiting

M302 corresponding the input terminal INTPU_2 Judgment if it is low level execute the next line, otherwise go on waiting

M303 corresponding the input terminal INTPU_3 Judgment if it is low level execute the next line, otherwise go on waiting

M304 corresponding the input terminal INTPU_4 Judgment if it is low level execute the next line, otherwise go on waiting

M305 corresponding the input terminal INTPU_5 Judgment if it is low level execute the next line, otherwise go on waiting

M306 corresponding the input terminal INTPU_6 Judgment if it is low level execute the next line, otherwise go on waiting

M307 corresponding the input terminal INTPU_7 Judgment if it is low level execute the next line, otherwise go on waiting

M308 corresponding the input terminal INTPU_8 Judgment if it is low level execute the next line, otherwise go on waiting

M309 corresponding the input terminal INTPU_9 Judgment if it is low level execute the next line, otherwise go on waiting

M310 corresponding the input terminal INTPU_10 Judgment if it is low level execute the next line, otherwise go on waiting

M311 corresponding the input terminal INTPU_11 Judgment if it is low level execute the next line, otherwise go on waiting

M312 corresponding the input terminal INTPU_12 Judgment if it is low level execute the next line, otherwise go on waiting

M313 corresponding the input terminal INTPU_13 Judgment if it is low level execute the next line, otherwise go on waiting

M314 corresponding the input terminal INTPU_14 Judgment if it is low level execute the next line, otherwise go on waiting

M315 corresponding the input terminal INTPU_15 Judgment if it is low level execute the next line, otherwise go on waiting

M316 corresponding the input terminal INTPU_16 Judgment if it is low level execute the next line, otherwise go on waiting

M401 corresponding the input terminal INTPU_1 Judgment if it is low level execute the next line, otherwise go on waiting

M402 corresponding the input terminal INTPU_2 Judgment if it is low level execute the next line, otherwise go on waiting

M403 corresponding the input terminal INTPU_3 Judgment if it is low level execute the next line, otherwise go on waiting

M404 corresponding the input terminal INTPU_4 Judgment if it is low level execute the next line, otherwise go on waiting

M405 corresponding the input terminal INTPU_5 Judgment if it is low level execute the next line, otherwise go on waiting

M406 corresponding the input terminal INTPU_6 Judgment if it is low level execute the next line, otherwise go on waiting

M407 corresponding the input terminal INTPU_7 Judgment if it is low level execute the next line, otherwise go on waiting

M408 corresponding the input terminal INTPU_8 Judgment if it is low level execute the next line, otherwise go on waiting

M409 corresponding the input terminal INTPU_9 Judgment if it is low level execute the next line, otherwise go on waiting

M410 corresponding the input terminal INTPU_10 Judgment if it is low level execute the next line, otherwise go on waiting

M411 corresponding the input terminal INTPU_11 Judgment if it is low level execute the next line, otherwise go on waiting

M412 corresponding the input terminal INTPU_12 Judgment if it is low level execute the next line, otherwise go on waiting

M413 corresponding the input terminal INTPU_13 Judgment if it is low level execute the next line, otherwise go on waiting

M414 corresponding the input terminal INTPU_14 Judgment if it is low level execute the next line, otherwise go on waiting

M415 corresponding the input terminal INTPU_15 Judgment if it is low level execute the next line, otherwise go on waiting

M416 corresponding the input terminal INTPU_16 Judgment if it is low level execute the next line, otherwise go on waiting
