PXM PiXiMo 18 User Manual

19
21. DIMENSIONS
512
12 - 24 V DC
max. 18 A
46 mA for 12 V DC
32 mA for 24 V DC
3
6 A / channel
16 bit
1
18
terminal block
YES
0,1 kg
35 mm (2 DIN rail modules)
90 mm
58 mm
- DMX channels
- power supply
- current consumption
- no-load current consumption
- output channels number
- outputs load capacity
- control accuracy
- programmable scenes
- built-in programs
- output sockets
- MASTER mode
- weight
- dimensions:
- width
- heigth
- depth
22. TECHNICAL DATA
35 mm
90 mm
58 mm
www.pxm.pl
DMX IN DMX OUT
GND
GND
OUTPUTS
B –G –R –
PX282
DC IN
The PX282 version equipped in 6A outputs and supporting RDM protocol
has been introduced to the production starting from 14260014 serial number.

PXM PiXiMo 18 Specifications

General

Brand	PXM
Model	PiXiMo 18
Category	Controller
Language	English
