PXM PiXiMo 18 User Manual

CHANNEL4 – MODE
- - - < 0 - 7 > Program1
- - - < 8 - 15 > Program2
- - - < 16 - 23 > Program3
- - - < 24 - 31 > Program4
- - - < 32 - 39 > Program5
- - - < 40 - 47 > Program6
- - - < 48 - 55 > Program7
- - - < 56 - 63 > Program8
- - - < 64 - 71 > Program9
- - - < 72 - 79 > Program10
- - - < 80 - 87 > Program11
- - - < 88 - 95 > Program12
- - - < 96 - 103 > Program13
- - - < 104 - 111 > Program14
- - - < 112 - 119 > Program15
- - - < 120 - 127 > Program16
- - - < 128 - 135 > Program17
- - - < 136 - 143 > Program18
- - - < 144 - 151 > OFF - - -
< 152 - 169 > -
< 170 - 199 > -
< 200 - 229 > -
< 230 - 255 > RGBD - -
Channel 4 – work mode settings
CHANNEL1 - red colour
CHANNEL2 - green colour
CHANNEL3 - blue colour
CHANNEL4 - operating mode selection
CHANNEL5 - speed settings (higher value - quicker changes)
CHANNEL6 - fade settings (higher value - smoother transition)
CHANNEL7 - lightness settings (higher value - stronger glow)
- possibility to control a given parameter of a selected mode
character ("-") - no possibility to control a given parameter of a selected mode
EFF mode (effect) channels desription
CHANNEL1
RED
CHANNEL2
GREEN
CHANNEL3
BLUE
CHANNEL5
SPEED
CHANNEL6
FADE
CHANNEL7
BRIGHTNESS
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x
x x x Strobo 10% x x
x x x Strobo 20% x x
x x x Strobo 50% x x
x x x x
character ("x")
8
Description guide of EFF mode settings
9. INDIVIDUAL SETTINGS
The PX282 module has an option that allows for changing individual settings. It enables
assigning any DMX address to every output channel. The simplest example of implementation of
this function is to control the lightness of one-colour LEDs connected to all outputs. In such case,
the same address must be assigned to all channels so that all outputs are controlled by one slider
on the control panel.

PXM PiXiMo 18 Specifications

General

Brand	PXM
Model	PiXiMo 18
Category	Controller
Language	English
