Pyle PDWM3100 - Replace the Battery; Controls and Functions; Front Panel

www.PyleUSA.com
5
3. REPLACE THE BATTERY
Two polar battery life is about 8 hours,
but it may vary according to the usage
conditions. When the battery power
displays as empty and ashing,
you should replace the batteries at once.
2. RECEIVER FUNCTION
CONTROLS AND FUNCTIONS
FRONT PANEL:
1. POWER BUTTON: Press this button to turn ON/OFF the unit
2. MIC 1 SELECTOR BUTTONS (UP/SET/DOWN): Allows control of LCD screen
and functions for Microphone 1.
3. MIC 2 SELECTOR BUTTONS (UP/SET/DOWN): Allows control of LCD screen
and functions for Microphone 2.
4. LCD SCREEN: Displays system status.
5. IR PORT: lntrared port for wireless lntrared Auto Sync System.
Pointing the handheld microphone's infrared port at the receiver's infrared
port to allow communication.
6. Recharge port: Put in the microphone to recharge.
1
2
3
4
5
6
