Pylontech Force-L2

19PIFP0301
7 / 13
2.2.3 Control Module FC0048M-100
(internal power supply)
Control Module (FC0048M-100) Display Panel
LED Button
Short Press
Display the LED panel for 20sec.
Long Press
(more than
5sec)
When all LED flash blue ●, loss the button, then it is chosen
115200 baud rate of RS485.
When all LED flash orange ●, loss the button, then it is chosen
9600 baud rate of RS485.
