Pylontech US2000C

Page 12
Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663
Residential Configuration
Item Amount
Rated
Power(kW)(1)
Max Power(kW,
60S)
Peak Power(kW,
15S)
Nominal
Capacity(kWh)
Usable
Capacity(kWh)
Min. Back-up
time(2)
UP5000
1 2.4 4.8 4.3 4.8 4.6
1.9hrs
2 4.8 9.6 8.6 9.6 9.1
3 7.2 14.4 13.0 14.4 13.7
4 9.6 19.2 17.3 19.2 18.2
5 12.0 24.0 21.6 24.0 22.8
6 14.4 28.8 25.9 28.8 27.4
7 16.8 33.6 30.2 33.6 31.9
8 19.2 38.4 34.6 38.4 36.5
9 21.6 43.2 38.9 43.2 41.0
10 24.0 48.0 43.2 48.0 45.6
11 26.4 52.8 47.5 52.8 50.2
12 28.8 57.6 51.8 57.6 54.7
13 31.2 62.4 56.2 62.4 59.3
14 33.6 67.2 60.5 67.2 63.8
15 36.0 72.0 64.8 72.0 68.4
16 38.4 76.8 69.1 76.8 73.0
(1) Rated Power is based on ideal operation temperature(10 - 45
℃
)
，
ensuring charging the power will decrease in levels when reaching full capacity.
(2) Min. Back-up time is based on rated power and related condition during beginning of life, in real application please consider the load.
