Page 23
Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663
2) Cable connection: Ground cable connection:
1) Based on metal directly touch between the module’s surface
and rack’s surface. If using painted rack, the corresponding
place shall remove the painting.
2) Install a grounding cable to the grounding point of the
modules.
Figure 13: Battery rack
Figure 14: Battery grounding point
Installation
