Pylontech US3000C Product Presentation

Page 12
Contact SegenSolar (PTY) Ltd | e: info@segensolar.co.za | t: 08780 20663
Residential Configuration
Item Amount
Rated
Power(kW)(1)
Max Power(kW,
60S)
Peak Power(kW,
15S)
Nominal
Capacity(kWh)
Usable
Capacity(kWh)
Min. Back-up
time(2)
UP5000
1 2.4 4.8 4.3 4.8 4.6
1.9hrs
2 4.8 9.6 8.6 9.6 9.1
3 7.2 14.4 13.0 14.4 13.7
4 9.6 19.2 17.3 19.2 18.2
5 12.0 24.0 21.6 24.0 22.8
6 14.4 28.8 25.9 28.8 27.4
7 16.8 33.6 30.2 33.6 31.9
8 19.2 38.4 34.6 38.4 36.5
9 21.6 43.2 38.9 43.2 41.0
10 24.0 48.0 43.2 48.0 45.6
11 26.4 52.8 47.5 52.8 50.2
12 28.8 57.6 51.8 57.6 54.7
13 31.2 62.4 56.2 62.4 59.3
14 33.6 67.2 60.5 67.2 63.8
15 36.0 72.0 64.8 72.0 68.4
16 38.4 76.8 69.1 76.8 73.0
(1) Rated Power is based on ideal operation temperature(10 - 45
℃
)
，
ensuring charging the power will decrease in levels when reaching full capacity.
(2) Min. Back-up time is based on rated power and related condition during beginning of life, in real application please consider the load.

Pylontech US3000C Specifications

General

Battery Type	Lithium Iron Phosphate (LiFePO4)
Nominal Voltage	48V
Capacity	74Ah
Discharge Current (Recommended)	37A
Discharge Current (Maximum)	74A
Communication	CAN, RS485
Cycle Life	6000 Cycles @ 25°C
Operating Temperature	-10°C to 50°C
Scalability	Up to 16 units in parallel
Certification	CE, UN38.3
