Pyronix ATLAS 4 User Manual

Rins141 Issue 7 Page 19
10.23 System Set / Unset Reporting Codes
Enter
Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
e.g. 2 digit code
Set A
Set B
Set C
Set D
Duress set
Duress unset
Confirmed alarm code
To use HEX codes, use the key to select the character required and the key to accept.
Reporting codes are automatically stored after pressing the
key.
10.24 User set reporting codes
Enter
Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
e.g. 2 digit code
Set User 1
Set User 2
Set User 3
Set User 4
Set User 5
Set User 6
Set User 7/Keyswitch
To use HEX codes, use the key to select the character required and the key to accept.
Reporting codes are automatically stored after pressing the
key.
10.25 User Unset reporting codes
Enter
Enter 2 digits for seven reporting codes. To disable an event insert blanks for both digits.
e.g. 2 digit code
Unset User 1
Unset User 2
Unset User 3
Unset User 4
Unset User 5
Unset User 6
Unset User 7/Keyswitch
To use HEX codes, use the
key to select the character required and the key to accept.
Reporting codes are automatically stored after pressing the
key.
