DIAGNOSTICS?
View PSUs?
View Inputs?
View Radio
Device Status?
Signal Strength?
Inputs?
Please Wait
299
3----------------
-----------------
Input [01]
Excellent [100]
Bells?
?-
Diagnostics
The diagnostics function shows all wireless (radio)
input and bell signal strengths and battery strengths.
Signal Strength (Inputs and Bells)
One of the most important factors for a reliable
wireless installation is the signal strength between
a wireless device and the panel. If a device is out of
range it will not be able to send events to the Enforcer
panel therefore it is recommended that a signal
strength test is performed before xing devices into
place. The Enforcer has an advanced signal strength
mechanism that operates by monitoring all inputs/bells
after 5 minutes from the start of the test. It will perform
this test every 16 seconds.
NOTE: When performing a signal strength test it is
recommended that the system is tested in the ‘worst
case scenario’ for example with all doors and windows
closed.
Once the function is entered, a count down from 300
will begin, when 0 is reached the input results display
will be shown, or press t during the count down
to go to the input display immediately, one of the
following will be displayed:
Result Action
- No device installed
? Waiting for device signal strength
information
0 Missing (reposition and retest)
1 Weak signal (reposition and retest)
2 Good install position
3 Excellent signal
The signal strength can also be read from the wireless
device LEDs.
GREEN LED = Good. RED LED = Bad
When the display is showing the input status, pressing
t will show each individual input and a detailed
signal strength reading will be shown as follows:
Result Action
Excellent [50 to 100] OK to install
Good [30 to 49] OK to install
Weak [0-29] Not OK to install
Missing [-] Not OK to install
Use
b
and
x
to scroll to:
Press
t
Press
x
Press
x
Press
t
Press
t
Press
t
Press
t
Press
t
Use [ ] Press
t
Press
t
Press
t
To Next Page
