Pyronix ENFORCER V11 Installation Guide

4
ENFORCER V11 INSTALLATION GUIDE
INTRODUCTION
The Enforcer is a wireless alarm system that has been designed to enable easy installation and minimal
maintenance. The Enforcer protects the property (domestic or commercial) with a multitude of unique features:
• Two Way Wireless Protection
• Signal Strength Indicator (SSI)
• Instant Two Way Device Control
• Pyronix High Security Wireless Protocol Encryption
• Programmable Wireless Supervision Time
• Intelligent Wireless Jamming Detection
Default codes
Master Manager Code: 2222
Engineer Code: 1111
SYSTEM OVERVIEW
Areas 4
Wireless zones (max)
64
32x zones on board (zones 1-32)
1x wireless expander (zones 35-66)
Wired zones (max)
34
2x zones on I/O board (zones 33-34)
4x wired expanders (zones 35-66)
Total zones 66
Outputs (max):
38
3x outputs on I/O board
1x output module
4 on each wired expander
1 on each wired keypad
User/Manager codes:
80
(Max 32 x wireless keyfobs)
Duress/Guard codes: 2
Code combinations: 4294967295 (fully encrypted rolling code)
Communications:
Additional to the on-board Wi-Fi module
DIGI-GPRS | DIGI-LAN | DIGI-PSTN | DIGI-PSTN/VOICE
Arming devices (max):
8
1x onboard keypad
3x wired keypads or internal/external proximity readers.
4x wireless keypads
4x tablets using HomeControlHUB application
Sirens: 2 wireless sirens or 2 wired sirens (in SCB mode)
Logs: 750
Remote arm and soak test
P
Event signalling to UDL
P
Memory type EEPROM
EN grade 2
Environmental class II

Pyronix ENFORCER V11 Specifications

General

App Compatibility	ProControl+
Battery Backup	Yes
Wireless Detectors	Yes
Wireless Siren	Yes
Repeaters	Yes
Two-Way Wireless Technology	Yes
Operating Temperature	-10°C to +40°C
Storage Temperature	-20°C to +60°C
Communication Options	PSTN
Wireless Zones	64
