Matrix 6/816 User Manual
RINS545-7 Page 13
4.2 Chime On/Off
Press `11
The keypad will sound an
acknowledgement tone each time,
signalling the chime has been toggled
on or off. However, there is no visual
indication if the chime is on of off.
4.3 Arm With Omits (Bypass)
Press `12
This starts the Arm with Omits
function.
Select the zone to be omitted, and
press ` to confirm. Repeat for all
zones.
Example shows Zone 6.
When all required zones have
been omitted, press - to
proceed
System asks for Arm Mode.
Press a, b, c or d to
select Arm Mode required
Example shows Arm Mode A.
The panel starts arming as normal
4.4 View Event Log
Press `13
The log shows the last event.
Example shows disarm event.
Use the [ and ] keys to
scroll through the log events
Example shows Zone 6.
When the display shown is seen,
you have reached the end of the
log
Press ` to exit the log
NOTE: To interpret the event log indication see the table on page 20.
