Python 872 User Manual

© 2011 Directed Electronics. All rights Reserved. 2
QRN5202 2011-03
Programming System Features
TheSystemFeaturesLearnRoutinedictateshowtheunitoperates.Itispossibleto
accessandchangemostofthefeaturesettingsusingtheControlbutton.
1. Openadoor.
2. Turntheignitionon,thenoff.
3. SelectaMenu.PressandholdtheControlbutton.Thenumberofsirenchirps
indicatesthemenunumber.1chirpindicatesmenu1,2chirps-menu2and
3chirpsformenu3.
4. Whenthedesiredmenuchirpsareheard,releasetheControlbutton.
5. SelectaFeature.PressandreleasetheControlbuttonthenumberoftimes
correspondingtothefeatureyouwishtochange.Thenpressandholdone
moretimetoselectthefeatures.
6. ProgramtheFeature.WhileholdingtheControlbutton,youcanprogramthe
featureusingtheremotecontrol.
Forfeatureswithonlytwooptions;
AUX
=option1while
AUX
=option2.
Forfeatureswithmorethantwooptions;
AUX
selectstheoptionsinascendingorder,
while
AUX
selectsthemindescendingorder.
Note:Pressing
AUX
buttonresetsthefeaturetothefactorydefault.
Once a feature is programmed:
• Otherfeaturescanbeprogrammedwithinthesamemenu
• Anothermenucanbeselected
• Thelearnroutinecanbeexitedifprogrammingiscomplete
To access another feature in the same menu:
1. PressandreleasetheControlbuttonthenumberoftimesnecessarytoadvance
fromthefeatureyoujustprogrammedtothenextoneyouwanttoprogram.
2. ThenpresstheControlbuttononcemoreandholdit.
To select another menu:
1. PressandholdtheControlbutton.
2. After3seconds,theunitadvancestothenextmenuandthesirenchirps,indi-
catingwhichmenuhasbeenaccessed.
The learn routine exits if any of the following occurs:
• Theopendoorisclosed
• TheignitionisturnedOn
• Thereisnoactivityfor30seconds
• TheControlbuttonispressedtoomanytimes
Bitwriter - Only Options
IfprogrammingwiththeBitwriter®,thelearnroutinecanbelockedorun-
locked.Ifthelearnroutinehaspreviouslybeenlocked,itmustbeunlocked
withBitwriter®-thiscannotbedonemanuallywiththeControlbutton.
TheBitwriter® givesyouaccesstoawiderrangeofsystemoptions.These
featuresandtheadjustmentsthatmaybeprogrammedaredescribedinthetable
below.Defaultsettingsareinboldtype.
Menu
Item
Feature Default Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 Zone4SensorType
None
Shock/
Omni
Field
Distur-
bance
TiltSen-
sor
GlassBreak(5)/
Ultrasonic(6)
2 SirenDuration
30 sec.
Options:1to180sec.
3 Aux/TrunkIconType
Trunk
Window Sunroof Audio Lights/Leftdr/Right
dr/RearHatch
4 Aux1TimedOutput
30 sec.
Options:1to90sec.
5 Aux1IconType
Pulsed
Trunk Window Sunroof Audio/Lights/Leftdr/
Rightdr/RearHatch/
Timed/Latched
6 Aux2TimedOutput
30 sec.
Options:1to90sec.
7 Aux2IconType
Pulsed
Trunk Window Sunroof Audio/Lights/Leftdr/
Rightdr/RearHatch/
Timed/Latched
8 Aux3TimedOutput
30 sec.
Options:1to90sec.
9 Aux3IconType
Pulsed
Trunk Window Sunroof Audio/Lights/Leftdr/
Rightdr/RearHatch/
Timed/Latched
10 Aux4TimedOutput
30 sec.
Options:1to90sec.
11 DieselStartDelay
Timer
15 sec.
Options:1to90sec.
12 TimerModeRuntime
12 min.
Options:1to16min.
13 TimerModeStarts
6 starts
Options:1/2/3/4to 24(Starts)inincrementsof2
14 Timermodeintervals
3 hr.
Options:1/2/3/4to24in2hourincrements
15
Smartstartlowtemp
0° (F)
Options:OFF,-20°to70°in10°increments
16
Smartstarthightemp
100° (F)
Options:OFF,40°to130°in10°increments
17
Smartstartlowbat-
tery(volts)
10.5V
Options:OFF,9Vto12.5Vin0.5Vincrements
18 Sensor1Level
7
Options:0to15inincrementsof1
19
StarterRelease
FineTune
6
(normal)
Options:0to20inincrementsof1
20
FeatureProgramming
Unlocked
Locked
21
TransmitterProgram-
ming
Unlocked
Locked
22
RemoteStartRuntime
12 min.
Options:1to60min.
23
VirtualTachFinetune
Not Ini-
tialized
Options:Notinitialized,0to1000in50millisecond
increments
Feature Menus
Defaultsettingsareinboldtype.Newfeaturesareboldwithgreybackground.
Menu 1 - Security
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1
SystemArmingMode
Active
PassiveArm
w/olock
Passive
Armw/
lock
Autore-arm
w/olock
Auto
re-armw/
lock
2
PanicMode
On
IgnOff
only
Off
3
ConrmationChirps
On w/Warn
chirps On
Onw/
Warn
chirpsOff
Offw/
Warn
chirpsOn
Offw/
warn
chirpsOff
4
SirenDuration
30 sec.
60sec.
5
Ign-controlledLocks
No Ign-
locking
Lock&
Unlock
LockOnly Unlock
Only
6
DoorLockPulses
Single
Double
Unlock
Only
Double
LockOnly
Double
Lock&
Unlock
7
DoorLockOutput
Duration
0.8 sec.
3.5sec. 0.4sec.
8
2ndUnlock
2nd unlock
on Ign-
control after
first unlock
2ndunlock
onIgn-
controlwith
rstunlock
9
ComfortClosure
No Comfort
Closure
Comfort
Closure1
Comfort
Closure2
10 HornFunction
Full Alarm
Only
SirenFunc-
tion20ms
SirenFunc-
tion30ms
Siren
Function
40ms
SirenFunc-
tion50ms
11 HoodSwitchtype
Normally
Open
Normally
closed
12 SensorFulltrigger
Single
Double
13 Door Switch Type Normally
open
Normally
closed
14 Trunk Switch Type Normally
open
Normally
closed
15 RemoteButtonunlock
(Ignoff)
On
Off
Menu 2 - Convenience
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 One-timeBypass
One time
bypass
Off
Onetime
bypassOn
2 NuisancePrevention
On
Off
3 OverridePulsecount
1
2 3 4 5
4 DoorTriggerError
Chirp
On
Off
5 Ign-controlledDome
light
On
Off
6 OEMAlarmDisarm
w/Aux-Trunk
On
Off
7 OEMAlarmDisarm
Output
With
Unlock
Before
Unlock
Remote
StartOnly
8 OEMAlarmDisarm
Pulses
1
2
9 Aux1Outputtype
Validity
Latch Latch/
reset/ign
30sec.
Timed
Off(5)/2nd
unlock(6)
10 Aux1Linking
No Linking
LinktoArm Linkto
Disarm
Linkto
Arm/
disarm
Linkto
RemoteStart
only
11 Aux2OutputType
Validity
Latch Latch
reset/ign
30sec.
Timed
Off(5)/2nd
unlock(6)
12 Aux2Linking
No Linking
LinktoArm Linkto
Disarm
Linkto
Arm/
Disarm
Linkto
RemoteStart
only
13 Aux3OutputType
Validity
Latch Latch
reset/ign
30sec.
Timed
Off(5)/2nd
unlock(6)
14 Aux3Linking
No Linking
LinktoArm Linkto
Disarm
Linkto
Arm/
Disarm
SmartKey
Control(Link
toRemote
StartOff)
15 Aux 4 Output Type Validity
Latch Latch
reset/ign
30sec.
Timed
Off(5)/2nd
Unlock(6)
16 Aux 4 Linking No linking
LinktoArm Linkto
Disarm
Linkto
Arm/
Disarm
Linkto
RemoteStart
Only
17 Aux/Trunk Output type Validity
Off 2ndunlock
Menu 3 - Remote start
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 TransmissionMode
Manual
Automatic
2 EngineCheckingMode
Virtual
Tach
Voltage Off Tachom-
eter
3 CrankingTime
0.6 sec.
0.8sec. 1.0sec. 1.2sec. 1.4(5)/1.6
(6)/1.8(7)
2.0(8)/
4.0(9)
4 RemoteStartRuntime
12 min.
24min. 60min.
5 ActivationPulseCount
1
2
6 TurboMode
No Turbo
Mode
On-1min. On-3min. On-5min. On-10min.
7 TimerModeRuntime
12 min.
3min. 6min. 9min.
8 FlexRelayFunction
Ignition 2
Acces-
sory2
Starter2
9 DieselStartDelay
Wait-to
Start input
Timed15
sec.
Timed30
sec.
Timed45
sec.
10 AccessoryduringDiesel
StartDelay
On
Off
11 Status2Output
Status
LatchRear
Defogger
PulseRear
Defogger
12 ParkingLightOutput
Constant
Pulsed Off
13 Anti-grindOutput
On
Off
14 TachModeStarter
Release
Normal
Increase Decrease
15 VehicleTemp
AutoReport
Off
On
16 Remote Start Safelock Off
On
Remote Pairing
Prepare the vehicle system to be Paired with a new remote
1. Openadoor.
2. TurnthekeytotheONposition.
3. Within5secondspressandreleasetheControlbuttonontheControlCenter
onetime.
4. Within5seconds,pressandholdtheControlbuttonontheControlCenter.
ThestatusLEDwillashonetimeandthesirenthenchirpstoconrmthevehicle
isreadyforremotepairing.
5. ReleasetheControlbuttonandproceedbelow.
Note: Ifnoremotepairingresults,thesystemwillexitafter60seconds.
Prepare the new remote to be Paired with the system
RemotePairmatchesyourLEremotetothesystem.MakesuretheLEremoteissetfor
thedesiredCar1(Default)orCar2operationforthesystemitwillbepairedwith.
1. Pressandholdthe
AUX
buttonfor8seconds.
Note:TheLOCKLEDindicatorwillturnonat3seconds.Pleasedisregardand
continuetohold.
2. WaitfortheTransmitLEDtolightsolidandtheremotetobeep.Releasethe
AUX
button.   
3. Pressthe
AUX
for1second.ThetransmitLEDwillblink3timesandbeep3
times. 
4. Within5seconds,pressthe
AUX
button.
5. ThevehiclesirenwillchirpandtheLEDindicatorsontheremotewilllightin
sequencewith sound. Youhave now successfullylearned the remoteto the
vehicleremotestartandsecuritysystem.
6. Pressthe
AUX
buttontwotimestoexitlearnroutineontheremote.Thetransmit
LEDwillturnoffandexittonewillsound..
Note: Pleaseseeinstallationguideforpairingwiththe1-waycompanionremote.
Basic Remote Functions
Button
Level
DIRECT
ACCESS
A U X
X 1
A U X
X 2
A U X
X 3
A U X
X 4
A U X
ARM SILENT ARM SENSOR BYPASS ARMED (SILENT
SENSOR)
ARMED (SILENT
TRIGGER)
A U X
DISARM SILENT DISARM VALET MODE CAR FINDER
A U X
REMOTE START RUNTIME RESET TIMER MODE SMART START REAR DEFOGGER
AUX
TRUNK RELEASE AUX 1 AUX 2 AUX 3 AUX 4
A U X
FUNCTION SHIFT CABIN TEMPERA-
TURE REQUEST
(2-WAY ONLY)
ARM STATUS
(2-WAY ONLY)
RUNTIME CHECK
(2-WAY ONLY)
LAST TRIGGER
REQUEST
(2-WAY ONLY)
Note: SeeOwner’sguideformoredetails
Table of Zones
Azone is represented by the number of status LED ashes usedby the
systemtoidentifyaparticulartypeofinput.
Zone Description Input Description
1 TrunkPin H1/7Bluewire
2 Instant trigger: a heavier impact
detectedbytheonboardshocksensor
Onboardshocksensor.
3 Doorswitchtrigger H1/8GreenorH1/6Violetwire
4 Instanttrigger:Foroptionalsensors OptionalMUXport
5 Ignitiontrigger H3/1Pinkwire
6 HoodPin H2/15Greywire

Python 872 Specifications

General

Brand	Python
Model	872
Category	Remote Starter
Language	English
