Q Acoustics M2 - Specification; Technical Specifications

22
Product
Qm2
Type
Streamlined Bluetooth
®
Soundbar
Amplifier
RMS Output Power
80W (2 x 20W + 40W)
THD (at rated power)
<1.00%
Frequency Response ±0.5dB
20Hz – 20kHz
S/N ratio (A Weighting)
-85dB
Mains Power
100~240V – 50~60Hz – 100W
Acoustics
Mid-High BMR 58mm x 58mm
Bass DVC 100mm x 150mm
Crossover 340Hz
System FQ Response +3/-6 dB
tbc
Power
Deep Standby <0.5W
Standby (Network Connected)
<2.0W
Idle
11.0W
Connections
Optical DAC 1 x 24-bit 48kHz Toslink
Bluetooth V4.1 Class II
CODEC
aptX, AAC, MP3, SBC
RCA Phono Maximum Sensitivity
2.10Vrms
3.5mm Maximum Sensitivity
1.10Vrms
Weight and Dimensions
Height
93mm
Width
550mm
Depth 330mm
Un-boxed Weight 6.0kg
Key Features
IPA
™
a
MoviEQ
™
a
LSG
™
a
Lip Sync
a
NFC
a
HDMI ARC
a
CEC
a
Bluetooth
®
a
AptX
®
a
AVRCP
a
DAC
a
BMR
a
DVC
a
Sub Out
Dynamic Bass
a
Specification
