28
INSTALLATION INSTRUCTIONS
WARNING: While in maintenance and service mode, ALL safety features are temporarily disable, therefore keep hands, feet and all
body parts away from the QUANTUM® Securement System when activated.
• All equipment and components MUST be installed and serviced by an experienced and trained technician.
• Safety eye glasses MUST be worn whenever installing or servicing this system.
• While the QUANTUM® is in Maintenance or Service Mode, earplugs MUST be worn.
• Before installation, check with local transportation authorities for specific regulations, standards, requirements and minimum/
maximum wheelchair location space and emergency exit requirements.
• Before installation, inspect the underside of vehicle floor, note utilities, frames, cross-members, fuel tanks and other possible
obstructions.
• This system is a complete, integrated system, do not alter or modify it in any way and do not interchange or substitute any
components. Any deviation from these recommendations is the responsibility of the installer.
• Do NOT install anchorages or any system components into faulty materials such as corroded metal, wood, plastic or fiberglass
panels.
• Vehicle anchor points may require reinforcement. The installer or manufacturer is responsible for ensuring anchorages are
installed into suitable floor and wall structures. Floor and wall strength MUST meet specific regulations, standards and applicable
performance requirements from local transportation authorities.
• Only use Hardware with a minimum Grade 8—meeting ASTM F835 ,SAE J429 or ASTM 574 specifications (depending on head style
and drive), and coated for adequate protection against corrosion per ISO 7253 or ASTM B117 or per customer requirements.
• The QUANTUM® Mounting Plate MUST be installed onto a flat surface.
• Any modifications to the QUANTUM® Mounting Plate MUST only be made where necessary, as a smaller plate size reduces the floor
load distribution. Always leave a minimum of 0.6” (15mm) adjacent the bolt hole in the plate.
• Two QUANTUM® Systems cannot be installed side by side because there MUST be a minimum pathway clearance of 22” when the
QUANTUM® System’s Arms are at their maximum width of 33.14”—check with local transportation authorities for specific regulations,
standards and requirements.
Installation Check List
