Qasair FA - Page 45

QASAIR Installation Instructions
43
‹‹ Twin Motor
213. BD10/12/15-WV-R/R Rear Register Kit
216. DR-300 Duct Length 300ø 1200mm
214. TMT-300 Transsition to 300ø
217. DR-300 CB Duct Length 300ø 1200mm
Colourbond
215. TR-2 Transition from DL-2 to 300ø
218. DR-300/45 Round Bend 45º
219. DR-300/90 Round Bend 90º
222. TMT-250 Twin Motor to 250sq
220. DL-2 /250SQ Rectangular to Square
Transition
223. DL-250 Duct Length 1200mm
221. TMT-250/300 Transition from 250sq
to 300º
224. HB-250 Horizontal Bend 90º
