QASAIR Installation Instructions
44
225. HB-250/45 Horizontal Bend 45º
226. TMT-250/90 Duct Deflector 250sq
Left or Right
227. BD/WV-250SQ Back Draft Wall 250sq
‹‹ Twin Motor
228. BD/WV-250SQ MGS Back Draft Wall
250sq Marine Grade Stainless Steel
231. CH-300 Chairman's Hat 300º
234. BD/RC-250SQ Back Draft Roof Cowl 250sq
229. BD/RC-2 Back Draft Roof Cowl
232. CH-300 CB Chairman's Hat 300º Colourbond
235. DLE-2-S/S CAP Flue Cap
230. BD/RC-2 CB Back Draft Roof Cowl
Colourbond
233. BD/SQ-RC-300 Back Draft Roof Cowl 300ø
236. CF-10/12/1500H Ceiling Flange
10/12/1500H
