PREPARATION
Installing / Removing the Battery
Match the two grooves of the battery pack with the 1.
corresponding guides on the back of the transceiver,
and then push it.
Press the battery pack until the release latch on the top 2.
of the transceiver locks. After hearing a “click” sounds,
the battery has been locked.
To remove the battery pack, slide up the release latch 3.
and remove the pack away from the transceiver.
Installing / Removing the Antenna
■
Installing the Antenna:
Screw the antenna into the connector on the top of
the transceiver by holding the antenna at its base
and turning it clockwise until secure.
■
Removing the Antenna:
Turn the antenna anticlockwise to remove it.
NOTE: Please turn off the transceiver before removing
the battery.
