4 – Managing Switches
Configuring a Switch
4-28 59226-00 B
S
4.7.5
SNMP Properties
Use the SNMP Properties dialog shown in Figure 4-12 to change SNMP
configuration parameters. After making changes, click the OK button to put the
new values into effect. To open the SNMP Properties dialog, select a switch in the
topology display or open the faceplate display, open the Switch menu and select
SNMP Properties.
Figure 4-12. SNMP Properties Dialog
NOTE: Since Read Community, Trap Community, and Write Community
settings are like passwords, they are write-only fields; the current
settings are not displayed.
