QM_XC7A35T_SDRAM Core Board User Manual V02
2. Getting Started
The QM_XCA35T_SDRAM core board includes below item:
Figure 2-1. QM_XC7A35T_SDRAM Top View
Below image shows the dimension of the QM_XC7A35T_SDRAM core board: 6.7cm x 8.4cm. The unit in
below image is millimeter(mm).
Figure 2-2. QM_XC7A35T_SDRAM Core Board Dimension
