QM_XC7A35T_SDRAM Core Board User Manual V02
2.1 Install Development Tools
The QM_XC7A35T_SDRAM core board tool chain consists of Xilinx Vivado 2016.4, Xilinx USB platform cable,
XC7A35T core board and 5V DC power supply. Below image shows the Xilinx Vivado 2016.4 development
environment which could be downloaded from Xilinx office website:
Figure 2-3. Vivado 2016.4
Below image shows the JTAG connection between Xilinx USB platform cable and XC7A35T core board:
Figure 2-4. JTAG Connection and Power Supply
TMS (Green)
TDI (Purple)
TDO (White)
TCK (Yellow)
GND (Black)
VREF (Red)
