Expansion Units Features
Just like the ES NAS system, the power button, Power/Status LED indicators and LCD status display
are conveniently located at the front panel on the EJ expansion units for easy access.
EJ1600 v2:
EJ1600:
Front Panel LEDs and Buttons
Item
Description
LED Color
Status
1
Power on button
System power on button
2
System Power LED
Blue
On = System power on
Off = System power off
3
Status
Green
Red
Green =The system is operating normally.
Red = The Power Supply Unit has been unplugged.
