QNAP TS-1279U-RP User Manual

29
LED
Color
LED Status
Description
LAN
Orange
Orange
The disk data is being accessed from the
network and a read/write error occurs during
the process.
Flashes
orange
The NAS is being accessed from the network.
10GbE
2
Green
Green
The 10GbE network expansion card is
installed.
Off
No 10GbE network expansion card is installed.
HDD
3
Red/
Green
Flashes red
The disk data is being accessed and a
read/write error occurs during the process.
Red
A hard disk drive read/write error occurs.
Flashes green
The disk data is being accessed.
Green
The hard disk drive can be accessed.
USB
3
Blue
Flashes blue
every 0.5 sec
1. A USB device (connected to the front USB
port) is being detected.
2. A USB device (connected to the front USB
port) is being removed from the NAS.
3. The USB device (connected to the front
USB port of the NAS) is being accessed.
4. The data is being copied to or from the
external USB or eSATA device.
Blue
A front USB device is detected (after the
device is mounted).
Off
1. No USB device is detected.
2. The NAS has finished copying the data to
or from the USB device connected to the
front USB port.
eSATA
3
Orange
Flashes
The eSATA device is being accessed.
Off
No eSATA device can be detected.
2
The 10 GbE network expansion function is only supported by the TVS-463, TVS-663,
TVS-863/863+, TS-879 Pro, TS-1079 Pro, TS-879U-RP, TS-1279U-RP, TS-EC879U-RP,
TS-EC1279U-RP, TS-1679U-RP, TS-EC1679U-RP, TS-870U-RP, and TS-1270U-RP.
3
This feature is only available on certain NAS models. Please refer to the product specification table
for details at www.qnap.com.

QNAP TS-1279U-RP Specifications

General

RAID levels	1, 5, 6, 10, JBOD
Storage drive size	2.5/3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA
Total installed storage capacity	0 TB
Maximum supported storage capacity	36 TB
Number of storage drives installed	0
Number of storage drives supported	12
Flash memory	512 MB
Internal memory	2 GB
Internal memory type	DDR3
Maximum RAM supported	4 GB
Tcase	69.1 °C
Bus type	DMI
L3 cache	3 MB
Processor cores	2
Processor model	i3-2120
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Conflict-Free processor	No
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
Thermal Design Power (TDP)	65 W
On-board graphics card model	Intel® HD Graphics 2000
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Cabling technology	10/100/1000Base-T(X)
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (3.2), NFS(v3), FTP, HTTP, HTTPS, Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
Compliance industry standards	IEEE 802.3ad
Fan	60 mm
Processor ARK ID	53426
Dimensions (WxDxH)	439 x 520 x 88 mm
Power requirements	100 - 240 VAC, 50/60Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Microsoft Windows XP, Vista (32/64-bit), Windows 7 (32/64-bit), Server 2003/2008 R2, Apple Mac OS X, Linux, UNIX
Noise level	54.6 dB
Security algorithms	256-bit AES, FIPS 140-2, SSH, SSL/TLS
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Chassis type	Rack (2U)
Product color	Black
LED indicators	HDD, LAN, Status
Number of fans	3 fan(s)
Power consumption (sleep)	68 W
Power consumption (typical)	165 W
Power supply unit (PSU) capacity	600 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Maximum number of PCI Express lanes	16
Memory channels supported by processor	Dual
Intel Identity Protection Technology version	1.00
On-board graphics card ID	0x102
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1100 MHz

Weight and Dimensions

Weight	15880 g
