b. Remove the screws that secure the rubber feet to the chassis.
Note
• The at head M3x5 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
c. Remove the rubber feet.
Reassembling the TVS-h1288X
Before you start, make sure you read the Repair requirements.
Warning
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Attach the rubber feet to the bottom of the chassis.
a. Position the chassis on its left side.
b. Align the holes in the rubber feet to the screw holes at the bottom of the chassis.
c. Attach the screws.
Note
• The at head M3x5 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
2. Attach the LCD display module to the front panel.
a. Align the screw holes in the LCD display module to the screw holes in the front panel.
| NAS Repair Manual
Category D NAS Models 117
