QNAP TS-1283XU-RP Repair Manual

No. Component
(Quantity)
Screw Type
(Quantity)
Screwdriver
(Torque)
Attached To
8 Expansion card slot cover
(3)
Flat head
M3x4
(1)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Rear panel
9 Fan duct
(1)
- - System board
10 Fan tray
(1)
Flat head
M3x4
(2)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
11 Power supply cage
(1)
Flat head
M3x4
(6)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
Rear panel
12 Rear panel
(1)
Flat head
M3x4
(11)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
13 Backplane
(1)
Flat head
M3x5
(18)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Backplane tray
14 Front top cover
(1)
Flat head
M3x4
(3)
Phillips #2
(5 kgf.cm / 4.34 lbf.in)
Chassis
15 System board
(1)
Flat head
M3x5
(19)
Phillips #2
(7 kgf.cm / 6.08 lbf.in)
Chassis
Backplane
16 Power supply unit
(2)
- - -
| NAS Repair Manual
Category E NAS Models 172
