• When installing four modules, use slots 1 and 3 for the first pair, and slots 2 and 4 for
the second pair. Ensure that each pair uses identical modules.
For details on slot numbering, see System Board.
Warning
• Only qualified personnel should perform the following steps. Failure to follow
instructions can result in serious injury or death.
• Observe electrostatic discharge (ESD) procedures to avoid damage to components.
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Power off the NAS.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Remove the top cover.
a. Loosen the two screws on the back of the top cover.
b. Slide the top cover back using the handle.
TS-x83XU User Guide
Installation and Configuration 31
