37
Chapter 7. Using the LCD Panel
The NAS provides a handy LCD panel for users to perform disk configuration and view the
system information.
When the NAS has started up, the server name and IP address will be shown.
N A S 5 F 4 D E 3
4 . 3 . 0 ( 2 0 1 7 0 2 1 4 )
After a few seconds, the panel will be automatically turned off. Then you can begin to
configure settings or view system information.
N A S 5 F 4 D E 3
1 6 9 . 2 5 4 . 1 0 0 . 1 0 0
Viewing and configuring system settings
When the name and firmware version of the NAS appear on the panel, press “ENTER” for
two seconds to view the Main Menu, which will automatically disappear if no further actions
are performed in ten seconds.
There are eight options on the Main Menu:
1. TCP/IP
2. Physical disk
3. Volume
4. System
5. Shut down
6. Reboot
7. Password
8. Back
1. TCP/IP
In TCP/IP, you can see the following information:
LAN1 IP Address
LAN1 Subnet Mask
LAN1 Gateway
LAN 1 PRI. DNS
LAN 1 SEC. DNS
(You can configure the above settings for every interface.)
Enter Network Settings
Network Settings – DHCP
To Next Page
