QNAP TS-219P User Manual

2. Physical
disk
The following options are available:
 Disk Info
 Back to Main Menu
The disk info shows the temperature and the capacity of the hard drive.
D i s k : 1 T e m p : 5 0
°
C
S i z e : 2 3 2 G B
3. Volume
This section shows the disk configuration of the NAS. The first line shows the RAID
configuration and storage capacity; the second line shows the member drive number
of the configuration.
R A I D 5 7 5 0 G B
D r i v e 1 2 3 4
If there is more than one volume, press the “Select” button to view the information.
The following table shows the description of the LCD messages for RAID 5
configuration.
LCD Display Drive configuration
RAID5+S RAID5+spare
RAID5 (D) RAID 5 degraded mode
RAID 5 (B) RAID 5 rebuilding
RAID 5 (S) RAID 5 re-synchronizing
RAID 5 (U) RAID 5 is unmounted
RAID 5 (X) RAID 5 non-activated
47

QNAP TS-219P Specifications

General

Processor family	Marvell
Processor frequency	1.2 GHz
Number of processors installed	1
Storage drive size	3.5 \
Storage drive capacity	0 GB
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	2
Flash memory	16 MB
Internal memory	0.5 GB
eSATA	Yes
USB 2.0 ports quantity	3
Dimensions (WxDxH)	102 x 216 x 150 mm
Power requirements	100 - 240 V AC, 50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Chassis type	Tower
Power supply unit (PSU) capacity	60 W

Weight and Dimensions

Weight	1740 g
