QNAP TS-253 Pro User Manual

54
Chapter 7. Install and Hot-swap Hard Drives
Caution:
 Before starting, please ensure that you turn off the NAS, disconnect the power
adaptor, network cable(s), and also remove any other device/cable that is attached to
the NAS.
 Please ensure that you wear an antistatic wrist strap during the entire process to
prevent electrostatic discharge. The crocodile clip should be connected to the ground.
7.1 Install Hard Drives
Follow the below steps to install hard drives on the NAS.
7.1.1. TVS-x63, TS-x53A, TS-563, TS-x53 Pro, TS-651, TS-851, TS-531P
1. Lift the hard drive lever and pull the tray out.
2. Install the HDDs
a. For 3.5” HDDs, secure the four screws in the back of the hard drive tray.

QNAP TS-253 Pro Specifications

General

RAID levels	0, 1, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	- GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Installed storage drive type	-
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Maximum supported storage capacity	- TB
Number of storage drives installed	0
Number of storage drives supported	2
Processor cores	4
Processor family	Intel® Celeron®
Processor frequency	2 GHz
Flash memory	512 MB
Internal memory	8 GB
Internal memory type	DDR3L
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	70 mm
Product color	Black
Number of fans	1 fan(s)
Cable lock slot type	Kensington
Type	NAS
Device class	Home & Home Office
Backup features	Cloud, iSCSI LUN
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Fan voltage	12 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.74 W
Power consumption (typical)	16.34 W
Power supply unit (PSU) capacity	90 W
Cables included	LAN (RJ-45)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	216 mm
Width	102 mm
Height	150 mm
Weight	1740 g
Package weight	2920 g
